Hytera AP525LF – analog PMR446 radio (IP66, 4000 mAh, USB-C, license-free)
Hytera AP525LF is the IP66 version of the popular AP515LF — identical functionality, higher degree of water and dust protection. The distinctive orange and black casing signals increased resistance: IP66 (water jets from any direction), MIL-STD-810G, 1.5m drop. 4000 mAh Li-Polymer, 25 h operating time, USB-C charging.
IP66
Water and dust protection
25 h
Operating time (5-5-90)
4000 mAh
Li-Polymer battery
USB-C
Charging from power bank
AP525LF vs AP515LF: The only difference is the degree of protection —
IP66 (AP525LF) vs IP54 (AP515LF). IP66 means resistance to strong water jets
from any direction — suitable for working in the rain, when washing devices with pressurized water
or in very humid environments. Functions, battery, and dimensions are identical.
Choose AP525LF when the work environment is wet or dirty.
Features
- VOX — hands-free communication with a headset
- CTCSS/CDCSS — sub-tones and digital codes for channel privacy
- Automatic scanning and Vote Scan
- BCL (Busy Channel Lockout) — busy channel lockout
- TOT (Time-Out Timer) — transmission time limit
- Voice prompts — channel and battery status confirmation
- 3-level noise reduction adjustment
- Monopole antenna with increased efficiency (+11% range vs standard)
Technical Specification
| Standard | PMR446 (license-free) |
|---|---|
| Band | 446.0 – 446.2 MHz |
| Transmit power | 0.5 W |
| Number of channels | 32 channels / 2 zones |
| Channel spacing | 12.5 kHz |
| Receiver sensitivity | 0.18 µV |
| Battery | 4000 mAh Li-Polymer, 3.85 V |
| Operating time | Up to 25 h @ 5-5-90 |
| Charging | USB-C, 10 W (full 1.8 h / 1 h = 8 h talk time) |
| Speaker | 3 W with noise reduction |
| Protection rating | IP66 |
| Resistance | MIL-STD-810G (1.5m drop) |
| Operating temperature | -30°C to +60°C |
| Dimensions | 105×55×29.5 mm |
| Weight | Approx. 200 g (with battery) |
Kit Contents
| Hytera AP525LF Radio | × 1 |
|---|---|
| 4000 mAh Li-Polymer Battery (BP4010) | × 1 |
| Wall charger with USB-C cable | × 1 |
| Belt clip | × 1 |
| Hand strap | × 1 |
